Specification & Properties
Core lateral length： 3、4、5、6、7.5、8、10、12、15mm
Foil width ： 0.04~0.08mm
Aluminum foil： Type 3003 and 5052
Maximum width： 1650mm, lengths depending on lateral length arrangements detailed as below
Ordinary specification of composite panels :
W1220 × L2440, please contact us for other special customary specification.
About the specifications of RBTCH honeycomb core, please feel free to inquire the download webpage.
